CCTV Cables

PVC Insulated and sheathed tinned copper braided video core CCTV cables

Information

Applications

Closed circuit Television (CCTV) cables are used to transmit the signals from CCTV Camera to the receiver with minimum distortion or attenuation. JAINAM CCTV cables comes in two types, namely 3 + 1 and 4 + 1 CCTV cables. Tinned copper braided video cables form the carrier for video signal and other cores form the carrier for power.

Features

Jainam CCTV Cables are designed to optimize the quality of video signals, which are transmitted through the braided video core. Topmost quality of construction of ATC Braided video core in Jainam CCTV cables ensures distortion free video signals and thus a clear picture over complete low frequency bandwidth of transmitting in such applications.

The high Impedance of video core ensures adequate signal strength, no reflection and best picture quality. Tinned copper braiding of 60 % coverage ensures complete elimination of EMI/RFI from the video signals and also provides a reduced DC resistance ground path. FR Sheathing is ideal for all Indoor and outdoor applications.

Cable Structure

Standard length cable packing :
Coils of 100, 200,300 and 500m or as per your requirement.

Technical DataTable

DataTable 1

PVC Insulated and sheathed tinned copper braided video core CCTV cables

Cable Size 3 + 1 4 + 1
Conductor Tinned Copper Tinned Copper
No. Of strands 14 14
Strands Dia. 0.1524 mm 0.1524 mm
Insulation PVC PVC
Thickness 0.55 mm 0.55 mm
Braiding Conductor Tinned Copper Tinned Copper
Braid Coverage 60% 60%
Overall Outer sheath PVC PVC
Color White White
Thickness 0.8 mm 0.8 mm
