FireX-FRLS

PVC insulated non sheathed single core cables for internal wiring

Information

Technical Data
  • Operating Temp: -15°c to max.+70°C
  • Nominal voltage: 1100 V
  • Test voltage: 3000 V
  • Range of product: 1 sq. mm to 6 sq. mm
  • Min. bending radius: 8 x cable diameter
  • FRLS-H properties: Flame retardant test as per IS 10810-58, 59,64, IEC 60332-1, ASTM-D 2843
Cable Structure

generally conforms to IS 694, BS 6004, IEC 60227, DIN VDE 0281-3, IS 8130 & IS 5831

Conductor:
EC grade flexible copper, generally conforms IEC 60228, IS 8130

Insulation:
specially formulated FRLS PVC compound with a high insulation resistance value PVC type – A

Colour:
Red, Green/Yellow, Blue, Black, Brown, Grey, Orange, White, Green, Yellow

*Any other Color on specific request can also be supplied

Cable features
  • Better Flame retardant property
  • Less Halogen acid gas Evolution
  • Resistant to tarnishing of copper
  • Excellent resistant to moisture, abrasion, grace, oil
  • Longer Flex Life
  • Excellent mechanical & electrical properties
  • Steam and boiling water resistant
  • Generally Conforming to : IS 694, CENELEC HD 21, IEC 60227, BS 6004, DIN VDE 0281
  • Tested by SGS, EIL, RITES, NPC
Application

FireX-FRLS
fixed installation in conduits and under plaster, for appliance wiring and distribution stations

Standard length cable packing:
Coils 90 and 180 m in carton boxes, reels

Technical DataTable

FireX-FRLSFRLS-H Properties / FR Properties
FireX-FRLS
Nominal cross sectional area of conductor Number/Nominal dia of strands Nominal insulation thickness Max.Overall diameter Max conductor resistance at 20°C Current rating
Casing Concealed
sqmm mm mm mm Ω/km Amps Amps
1 14/0.30* 0.7 3.2 18.1 14 13
1.5 22/0.30* 0.7 3.4 12.1 18 16
2.5 36/0.30* 0.8 4.2 7.41 24 20
4 56/0.30** 0.8 4.8 4.95 32 26
6 84/0.30** 0.8 6.4 3.30 36 32
  • * Class 2 flexible conductor
  • ** Class 5 flexible conductor
FRLS-H Properties / FR Properties
Test Aim Specification Specified Values
Limited Oxygen Index Test To find the percentage of oxygen required for supprting burning of cable at room temperature IS 10810-58 > 29%
Limited Temperature Index Test To find at what temperature the normal oxygen content of 21% in air will support burning of cable IS 10810-64 > 250°
Smoke Density Rating(Light Absorption) To determine the visibility during burning of cable ASTM D 2843 < 60%
Halogen Acid Gas Generation To find the amount of Hydrochloric acid gas evolved during burning of cable IS 10810-59 < 20%
