PVC Flat – 3 & 4 Core

PVC insulated 3-4 core sheathed flat cables for internal wiring

Information

Technical Data
  • Operating Temp: -20°c to max.+80°C
  • Nominal voltage: 1100 V
  • Test voltage: 3000 V
  • Min. bending radius: 6 x cable diameter
  • Flame propagation: Flame retardant test as per IEC 60332-1
Cable Structure

generally conforms to, CENELEC HD 21, UL-83, IEC 60227, BS 6500, DIN VDE 0281, IS 694

Copper:
EC flexible copper generally conforms to IEC 60228, DIN VDE 0295,IS 8131

Insulation:
PVC insulation compound TI-1

Outer Sheath:
Special PVC : Black, Blue

*Any other Color on specific request can also be supplied

Cable features
  • Good insulation properties when submerged in winter
  • Quality backed by 16 years experience in cable industry
  • Excellent resistant to moisture, abrasion, grace, oil
  • Longer Flex Life
  • Excellent mechanical & electrical properties
  • Generally Conforming to : CENELEC HD 21, IEC 60227, UL-83, BS 6500, DIN VDE 0281, IS 694
  • Approved by GWSSB, R&B
  • Tested by SGS, EIL, RITES, NPC
Application

PVC Flat – 3 & 4 Core
Jainam submersible pump cables are used as supply and control cables for engines for submersible pumps, underwater lighting, and floating switches etc. up to the depth of 500 m and water temperature up to +75°C. These cables are ideal for outer installations in dry, moist and wet environments but however not suitable for explosive areas.

Standard length cable packing:
Coils 100, 200,300 and 500, 1000m. in wooden reels

Cable Design

A submersible Pump cable is a specialized product to be used for submersible pumps in a deep well. The area of installation is physically restrictive, and the environment is very hostile. Jainam is designed and manufactured keeping in mind these factors to achieve the highest possible degree of reliability.

Cores colour: Core Identification
Color coding As per IEC 60227 As per IS 694
3 Core Black, Light Blue and Brown Red, Yellow and Blue
4 Core Black, Light Blue, Brown, Yellow with Green Line/ Green with Yellow Line Red , Yellow, Blue, Green / Black

Technical DataTable

PVC Flat – 3 corePVC Flat – 4 corePVC Flat – 3 core as per IS 694 : 1990 with ISI mark
PVC Flat – 3 core
Conductor PVC Insulation PVC Sheath Conductor Resistance at 20°C (max) Current Rating at 40°C
Nominal Area in Nos. & Dia. of wire Nominal Thickness Nominal Core Dia. Nominal Thickness Approx. Overall Dimensions
Thickness Width
Sq. mm. Nos./mm mm mm mm mm mm Ω/km Amps.
1.5 22/0.30 0.8 3.25 1.15 6 12.8 12.1 14
2.5 36/0.30 0.9 3.84 1.15 6.4 14.6 7.41 18
4 56/0.30 1 4.5 1.15 7.4 16.8 4.95 26
6 84/0.30 1 5.3 1.15 7.9 18.7 3.30 31
10 140/0.30 1 6.5 1.4 9.9 23.7 1.91 42
16 224/0.30 1 8 1.4 11.4 28 1.21 57
25 350/0.30 1.2 10.1 2 14.7 35.5 0.780 72
35 490/0.30 1.2 11.3 2 16.2 39.5 0.554 90
50 703/0.30 1.4 13.6 2.2 18.3 45.5 0.386 115
70 988/0.30 1.4 15.3 2.2 20 51 0.272 143
95 1349/0.30 1.6 18 2.4 23.5 60 0.206 165
  • The number of wires is approximate and wire diameter is nominal; they shall be such as to satisfy the requirements of conductor resistance as per Class 5 of IEC 60228 / DIN VDE 0295 / IS 8130 / BS 6360
  • In view of continuous improvements in our design and process, specifications given here in are subject change without notice.
PVC Flat – 4 core
Conductor PVC Insulation PVC Sheath Conductor Resistance at 20°C (max) Current Rating at 40°C
Nominal Area in Nos. & Dia. of wire Nominal Thickness Nominal Core Dia. Nominal Thickness Approx. Overall Dimensions
Thickness Width
Sq. mm. Nos./mm mm mm mm mm mm Ω/km Amps.
1.5 22/0.30 0.8 3.25 1.3 6 15.8 12.1 14
2.5 36/0.30 0.9 3.84 1.3 6.5 18 7.41 18
4 56/0.30 1 4.5 1.45 7.6 21 4.95 26
6 84/0.30 1 5.3 1.5 7.9 24.3 3.30 31
10 140/0.30 1 6.5 1.8 9.9 29.7 1.91 42
16 224/0.30 1 8 1.95 11.8 36 1.21 57
25 350/0.30 1.2 10.1 2 14.7 45.1 0.780 72
35 490/0.30 1.2 11.5 2 16.2 50.1 0.554 90
50 703/0.30 1.4 13.6 2.2 18.3 58.1 0.386 115
70 988/0.30 1.4 15.3 2.2 20 66.5 0.272 143
95 1349/0.30 1.6 18 2.4 23.5 77.3 0.206 165
  • The number of wires is approximate and wire diameter is nominal; they shall be such as to satisfy the requirements of conductor resistance as per Class 5 of IEC 60228 / DIN VDE 0295 / IS 8130 / BS 6360
  • In view of continuous improvements in our design and process, specifications given here in are subject change without notice.
PVC Flat – 3 core as per IS 694 : 1990 with ISI mark
Conductor PVC Insulation PVC Sheath Current Rating at 40°C
Nominal Area in Nos. & Dia. of wire Nominal Thickness Nominal Thickness Approx. Overall Dimensions
Thickness Width
Sq. mm. Nos./mm mm mm mm mm Amps.
1.5 22/0.30 0.6 0.9 5.2 11.3 14
2.5 36/0.30 0.7 1 6.2 13.3 18
4 56/0.30 0.8 1 7 15.6 26
6 84/0.30 0.8 1.1 7.4 17.7 31
  • The number of wires is approximate and wire diameter is nominal.
  • They shall be so as to satisfy the requirements of conductor resistance as per
    • • The number of wires is approximate and wire diameter is nominal.
    • • They shall be so as to satisfy the requirements of conductor resistance as per
