PVC Unarmoured Cables

Copper conductor, pvc insulated, un-armoured cables, Cable Code YY

Information

Technical Data
  • Operating Temp: -20°c to max.+90°C
  • Nominal voltage: 1100 V
  • Test voltage: 3000 V
  • Insulation resistance: Min. 10 MΩ x km
  • Min. bending radius: Single core: 15 X Overall diameter, Multi core: 12 X Overall diameter
  • Flame propagation: Flame retardant test as per IEC 60332-1
Cable Structure

generally conforms to IS 1554-1, IEC 60502-1, BS 6346

Conductor:
Material – Copper According to VDE 0295 class 1 or 2 (IEC 60228,IS 8130)

Insulation:
PVC Type A as per IS:5831

Inner Sheath:
PVC

Outer Sheath:
PVC TYPE ST-1 OF IS : 5831

*Any other Color on specific request can also be supplied

Application

PVC Unarmoured Cables
Power cables for energy supply are installed outdoors, in underground, in water, indoors, in cable ducts, power stations, for industry and distribution boards as well as in subscriber networks, where mechanical damages are not to be expected.

Standard length cable packing:
Coils 100, 200, 300, 500, 1000 m. in wooden reels

Cable Design

Color Coding: AS IS 1554 ( Indian Standard )Color coding: AS IEC 60502 Part-1, B.S. 6346
Color Coding: AS IS 1554 ( Indian Standard )
Single core 2 Core 3 Core 4 Core 5 Core
Red or Black Red, Black Red, Yellow, Blue Red, Yellow, Blue, Black Red, Yellow, Blue, Black, Grey
Color coding: AS IEC 60502 Part-1, B.S. 6346
Single core 2 Core 3 Core 4 Core 5 Core
Black or Yellow/Green Blue and Brown or Yellow-Green and Black Brown, Black, Grey or Yellow/Green, Blue, Brown Blue, Brown, Black, Grey or Yellow/Green, Brown, Black, Grey Blue, Brown, Black, Grey, Black or Yellow/Green, Blue, Brown, Black, Grey
